Follow-Up Discussion on Use of Object-Oriented and Recap of Design Changes (Week 5).

State Transition and Activity Diagram (Week 4).

Sequence and Collaboration Diagram (Week 3).

Section Headings (create each heading on a new page with TBD as content except for sections listed under New Content below).

Be sure to update the fields of the TOC so it is up-to-date before submitting your project.

Use Word: Paste models into the Word document.

Create the deliverables described in the New Content section below for Project Description and Use Case Model.

Create the Object-Oriented Design Document shell.

Submit your project proposal to the instructor for approval.

This week's project deliverables are the following:

Other business functions are out of scope (for example, calendaring, customer management, delivery, etc.).

Assume that the customers already exist.

The project will support ordering and payment processing.

Following are the scope and assumptions for this design: The object-oriented design that you create will be for an ordering system for your chosen company. As you proceed through each project phase, you will add content to each section of the final design document to gradually complete the final project. You will be asked to create the shell document for the final Key Assignment project deliverable that you will be working on for each phase. Your first task will be to select an enterprise to use as a basis for the project. Your instructor will tell you how to submit this proposal and what notification will be given for project approval.įor the assignments in this course, you will be developing an object-oriented design document.

Approval should be sought within the first several days of the course. Select an enterprise, and submit your proposal to your instructor before proceeding with the assignments for the course. You should be familiar with the organization to allow focus on the object-oriented design. This organization will be used as a basis for each of the assignments throughout the course. This organization can be real or fictitious. The first step is to select an organization for your object-oriented design. Week 5: Revision of full design for a new requirement final discussion of OO and UML.Week 4: Section 4: State Transition and Activity Diagram.Week 3: Section 3: Sequence and Collaboration Diagram.The final Key Assignment will be comprised of the following: The project will culminate in a final Key Assignment draft that will be due in Week 4. Additional information and deliverables for each Individual Project will be provided in the assignment description for that project. You will work on a part of the project each week. Throughout this course, you will be working on an object-oriented project to design an ordering system for a company of your choosing.
